Hüttenhölscher Line obradni centar

This Hüttenhölscher Line multi-spindle drilling machine was manufactured in 2012. It features a PC-controlled function sequence under Windows 7 with TwinCAT, a 6-station loading gantry, and a 2-axis gantry robot. The machine includes a vacuum generation by ejector and multiple conveyor lines for efficient material handling. Ideal for high precision drilling with its advanced control system. Contact us for more information about this machine.
Location: DE
Control: PC-controlled function sequence under Windows 7, TwinCAT
Thickness: 16–25 mm
2-axis gantry robot; Y/Z axes with servo motors; travel distances: Y-axis 8500 mm, Z-axis 1500 mm
Stack height: max. 1000 mm (60 parts) incl. protective plate
Feeding/removal: manual cross transfer carriage
width: 350–710 mm
Part dimensions
2-station drilling station
Base frame as welded construction with machined screw-on surfaces
2x toothed belt conveyors V = 1.5 m/sec
2x pneumatic lift for toothed belt conveyors
2x stoppers for cabinet parts
dampened by shock absorbers
2x pneumatic double clamping cylinders
controlled by ball screw and servo motor
moved to side height (measuring the side height)
2x pneumatic cross alignment ruler (plausibility check)
2x vacuum clamping units in the drilling machine table
2x 0-line controllable
Support
Support can be moved in the X direction by means of a servomotor
2x drilling gear (support 1)
Support equipped with 2 units (machining from above)
Individually movable in Y direction by servomotor
Individually movable in Z direction by servomotor
Drilling gear a = 32 mm
adjustable with frequency converter
drill chuck Ø 10h7 with grub screw
Callable spindles
8000 rpm
Two 16-spindle drilling gears
Groove saw (support 1)
Sawing units for cutting special rear wall grooves
Sawing unit with tool holder
speed control via frequency converter
Pneumatically pilot-controlled working position
2x milling spindles right/left at the front edge (support 1)
Pneumatically pilot-controlled working position
Additional equipment (automation
handling
guarding
conveyors)
Loading/handling
6-station loading gantry
Suction crossbeam with four-circuit vacuum supply
vacuum generation by ejector
Double part detection
Portal supports
4 stacking stations
1 hand rest station (automatic/manual feeding)
1 removal station (automatic/manual removal)
Side feed range
Protective plate sizes
1380 mm x 780 mm
1220 mm x 720 mm
1120 mm x 620 mm
2290 mm x 620 mm
Thickness: 25 mm
Thickness: max. 28 kg
Floor roller conveyor / stack feed
4 roller conveyor lines
930 mm wide x 3600 mm long
AH 300 mm
Support stations / automatic feeding
Transport section 950 mm wide x 4100 mm long
integrated side stop
Manual feeding
Toothed belt section 900 mm wide x 2500 mm long
Transfer shuttle
Toothed belt section 900 mm wide x 2500 mm long
horizontal stroke approx. 2500 mm by three-phase motor
Return
Transport section 950 mm wide x 4000 mm long
pneumatic stopper
90° rotary unit
Vacuum suction cup
pneumatic stroke
rotation by three-phase motor by +/- 90°
Discharge stations / automatic removal
Transport 950 mm wide x 3000 mm long
positioning of cabinet parts by encoder
Manual removal
Toothed belt section 900 mm wide x 3000 mm long
Protective system for feeding
45 m protective fence with 3 access doors
2 sliding doors for feeding the floor roller conveyors
Input
request
and release by acknowledgment
